Nussbaum 2-Post Lift SPL OTTO 9

Nussbaum 2-Post Lift 9,000lb Capacity:

The OTTO 9 is the reinvention of car lifting and workshop design. Over 75 years of NUSSBAUM innovation and experience has lead us to this revolutionary design. We are proud to name this lift after our founder Otto Nussbaum. The OTTO 9 is named for the benefits it gives to operators, as well as the productivity in terms of space and dollars to the owner. And this lift is 100% manufactured in the USA.

Why is the OTTO 9 so revolutionary?

  • It changes the way you lift your vehicles
  • It changes the way your workshop looks
  • It prepares your workshop for electric vehicles including battery exchanges
  • It will always provide the best access for the job
Ask a Question About this Product
  • Features & Benefits
  • Literature/Downloads

SPL9 2-POST LIFT FEATURES:

  • Double jointed rear arms
  • OTTO is ready for new technologies like electric cars and battery exchanges. This arm allows for new service opportunities with electric cars. The patent-pending lift offers full service underneath the car which allows all covers to be removed to get to the vehicles batteries
  • Always open the doors
  • Obstruction free access to the areas you need to work on
  • Lift 100% manufactured in the USA

Tech Spec:

• Capacity: 9,000 lb
• Pick up pad height min: 4.5 inch
• Front arms extension min-max: 27.25 – 43.5 inch
• Rear arm extension min-max: 39.5 – 59 inch
• Inside column width: 105 inch
• Lifting height: 73.5 inch – 83in (XL Option)
• Overall width min: 120 – 124 inch
• Drive-through width min: 94.75 inch
• Overall height min: 143 inch
• Power supply (V/ph): 208/230 / 1 ph
• Motor power: 3.5 hp
