Nussbaum 2-Post Lift OTTO 12

Nussbaum 2-Post lift 12,000lb Capacity:

The OTTO 12 is equipped with HF NT series is a revolutionary hydraulic two post lift. The patented HyperFlow® technology allows the lift to be perfectly and automatically synchronized without cables or pulleys. A double hydraulic circuit with 4 cylinders makes a mechanical locking system no longer necessary. This new generation of lifts are the perfect solution to increase the productivity and efficiency of the workshop while reducing cost of ownership.

Ask a Question About this Product
  • Features & Benefits
  • Videos
  • Literature/Downloads

OTTO12 2-Post Lift Features:

  • No Equalization Cables: Patented HyperFlow® technology allows the lift to equalize itself each time it reaches its top position.
  • The OTTO 12 has the fastest lifting and lowering times in the industry. 20 seconds up / 16 seconds down with No Battery Required.
  • Unique double-jointed arms.
  • Fast lifting and lowering times guarantee high cost effectiveness
  • Powerful and uniform lifting with control lever
  • No floor connection and no top static connection of the columns is necessary
  • NT System – double hydraulic system replaces mechanical locks
  • Hyperflow Technology ensures synchronization without cables or pulleys
  • Nearly wear-free hydraulic cylinders
  • Self-equalization system for the hydraulic system
  • Far reach arms to pick up long vans with lowest lifting point
  • Low noise oil-submerged motor

Tech Spec:

  • Capacity: 12,000lb
  • Lifting Height Max: 80.75in
  • Column Height: 156in
  • Drive-through width min: 109.75in
  • Power supply (V/ph): 208/230/ 1ph
  • Motor Power: 3ph
